AryaOS Site page¶

The AryaOS Site page is the single most important admin surface on the device. It edits the site configuration in /etc/aryaos/aryaos-config.txt. Every PyTAK gateway inherits this file. The page also controls onboarding, radios, updates, VPN, and support tools. Open it from Cockpit's menu, or directly at https://aryaos-xxxx.local/admin/ > AryaOS Site.

The AryaOS Site page in Cockpit - TAK destination, device role, radios, TLS, sensor services, updates, backup, and decommission cards

How saving works

The page edits known keys in place and preserves everything else in the file. This includes comments. Most cards apply immediately. But the TAK destination and TLS fields at the top only take effect when you press Save & restart sensors (or Save only) at the bottom of the page. See Save & restart. Cards with their own buttons act on their own.

The cards appear in the order below.

System time¶

What it does. Shows the browser clock, device clock, difference, time source, state, and device time zone.

Press Sync from this browser when GNSS and network time are unavailable. Confirm the warning and provide administrator access when Cockpit asks.

AryaOS samples the browser clock after authorization. It pauses Chrony, sets the device clock, saves a last-good clock floor, and resumes Chrony.

AryaOS also updates a hardware clock when one is present. This step is best effort because many devices lack one.

Chrony can correct the clock later when GNSS, NTP, or a validated tactical peer becomes available.

Time changes affect security and records

A large time change can reorder logs and change certificate checks. Verify the browser clock before you confirm.

Backend: aryaos-time-bootstrap set-browser runs through Cockpit's authenticated administrator channel. The public landing page and CGI endpoints cannot set time.

TAK destination¶

What it does. Sets where local CoT feeders send their Cursor on Target (CoT) events, chooses the ADS-B decoder, and names the UAT dongle.

Field	Config key	Default	Meaning
Site COT_URL	`COT_URL`	`udp+wo://127.0.0.1:28087`	Where every local feeder sends CoT
ADS-B decoder	`ARYAOS_ADSB_DECODER`	`readsb`	`readsb` or `dump1090_fa`
UAT (978 MHz) RTL-SDR serial	`ARYAOS_UAT_978_DEVICE`	`stx:978:0`	EEPROM serial dump978-fa binds to

The default Site COT_URL feeds the local COTBridge hub on udp+wo://127.0.0.1:28087. COTBridge then forwards that stream to Mesh SA and/or a TAK Server through its own lanes.

Keep the default unless you know why

For almost every deployment, leave COT_URL pointed at the COTBridge hub. Configure the actual upstream in the COTBridge lane editor. Only change COT_URL when you deliberately bypass COTBridge. This is the CoT routing invariant: feeders > cotbridge > Mesh SA / TAK Server.

The ADS-B decoder drop-down offers readsb (RTL-SDR / SoapySDR / HackRF) and dump1090-fa (FlightAware). Only one 1090 MHz decoder runs at a time.

Changing the decoder needs a service switch too

Setting ARYAOS_ADSB_DECODER records which decoder to enable. It does not start or stop systemd units. Reapply the device role after you change the decoder. The role enables the selected decoder and disables the other. See Radios & SDRs for the full procedure.

The UAT serial must differ from the 1090 MHz serial. See Radios (RTL-SDR) below and Radios & SDRs.

Device role¶

What it does. Chooses which sensor pipelines run on this unit. The CoT core includes COTBridge, LINCOT, GPSCOT, and gpsd. This core always runs. The role enables its sensor services at boot and stops the rest.

Role	Pipelines
Multi-sensor	All pipelines (ADS-B, AIS, drones)
Air	ADS-B 1090/978 aircraft
Maritime	AIS vessels
C-UAS	Drone detection
Relay	CoT routing only (no sensors)

The card lists the exact sensor services the selected role will enable ("Sensor services for this role. ..."). Press Apply role. You will be asked to confirm. This is because services outside the chosen role are stopped and disabled at boot.

Config key: the choice is persisted as ARYAOS_ROLE in the site config and applied by the aryaos-role set helper. Full unit-by-unit detail is in Device roles.

Applies immediately

Unlike the TAK destination fields, applying a role runs right away and does not wait for Save & restart sensors.

Onboarding hotspot password¶

What it does. Sets (or removes) the WPA2 password on the device's onboarding Wi-Fi hotspot.

When no known Wi-Fi is in range, AryaOS broadcasts its onboarding hotspot through Comitup. The hotspot is open by default. Enter 8-63 characters and press Save hotspot password to protect it. Press Remove password (open AP) to return to an open hotspot.

File touched: /etc/comitup.conf - the card writes the ap_password: setting (commenting it out re-opens the AP), then restarts comitup.

Applies to the next hotspot

A password change applies the next time the hotspot comes up. Reboot the device to force it. If you are currently connected over the hotspot, changing it will drop your connection. See Wi-Fi & onboarding hotspot.

MANET fallback (IPv4LL)¶

What it does. Keeps ordinary Ethernet usable when it has carrier but the attached MANET has no DHCP server. With the checkbox enabled, NetworkManager assigns a 169.254.x.x/16 address only when no other IPv4 address is available. DHCP automatically replaces it when service appears.

Press Apply setting after changing the checkbox. AryaOS updates current and future DHCP Ethernet profiles but does not reconnect an active interface. Thus, it cannot deliberately cut off the Cockpit session you are using. The setting takes effect on the next Ethernet activation or reboot. Static profiles and the AntSDR sensor link are excluded.

Backend: aryaos-ipv4ll, with persistent key ARYAOS_IPV4LL_FALLBACK. See DHCP-less Ethernet and MANET fallback.

Radios (RTL-SDR)¶

What it does. Lists the RTL-SDR dongles the device can see and lets you write a new EEPROM serial to each one. Thus, AryaOS can tell your 1090 MHz and 978 MHz sticks apart.

AryaOS selects dongles by EEPROM serial:

stx:1090:0 - ADS-B 1090 MHz (readsb / dump1090-fa)
stx:978:0 - UAT 978 MHz (dump978-fa), matching the UAT serial in TAK destination

The table shows each dongle's index, device string, and current serial. It also provides a New serial field and a Write button. Use the refresh icon to rescan. Serials must use 1-32 characters from A-Z a-z 0-9 : . _ -.

Backend: the aryaos-sdr helper (list and set-serial).

Replug the dongle after writing

Writing a serial briefly stops the SDR services (readsb, dump1090-fa, dump978-fa, ais-catcher) and then restarts the ones that were running. The new serial is not visible until you replug the dongle or reboot, then rescan. Full guidance is in Radios & SDRs.

Site-wide TAK TLS certificates¶

What it does. Uploads one set of TLS client credentials that every PyTAK gateway inherits, so you do not have to install certs per-service.

Provide PEM files:

Upload	Config key	Installed to	Mode
Client certificate	`PYTAK_TLS_CLIENT_CERT`	`/etc/aryaos/tls/client.pem`	`0644`
Client key	`PYTAK_TLS_CLIENT_KEY`	`/etc/aryaos/tls/client.key`	`0640`, group `tak-certs`
CA chain (optional)	`PYTAK_TLS_CLIENT_CAFILE`	`/etc/aryaos/tls/ca.pem`	`0644`

Press Install certificates. The card writes the files and records their paths. It also shows the installed files. Certificate and key must be present together.

The Do not verify server certificate checkbox sets PYTAK_TLS_DONT_VERIFY=1.

Lab only

PYTAK_TLS_DONT_VERIFY disables TLS server-certificate verification and must never be left enabled in the field.

Converting a .p12 bundle

Uploads must be PEM. If your TAK Server gave you a .p12, convert it first:

openssl pkcs12 -in bundle.p12 -out client.pem -clcerts -nokeys
openssl pkcs12 -in bundle.p12 -out client.key -nocerts -nodes

Certificates apply after you press Save & restart sensors. In most cases the TAK connection card below is easier. It installs certs from a data package or enrollment URL automatically.

TAK connection¶

What it does. Connects the whole appliance to a TAK Server in one step. Import an ATAK/iTAK connection data package, or paste a one-time tak:// enrollment URL. AryaOS installs the certs under /etc/aryaos/tls and enables COTBridge forwarding to the TAK Server.

The status table at the top of the card reports:

Enrollment - configured or not
Import service - ready or not
TAK target - the resulting COT_URL
TLS material - whether cert, key, and CA are present
Last updated / Detail when available

To enroll with a URL: paste the one-time tak://com.atakmap.app/enroll?host=...&username=...&token=... string into One-time enrollment URL and press Enroll.

To import a package: choose a .zip or .dpk connection package under Connection package and press Import package. Use Refresh status to re-read state.

On success the card reports the TAK target and that COTBridge forwarding was updated - so this card configures the upstream lane for you.

Preferred way to connect to a TAK Server

This card is the easiest path to a working TAK Server connection. It handles TLS material and the COTBridge lane together. For the manual lane approach, see Connect to a TAK Server and the COTBridge lane editor.

Sensor services¶

What it does. Shows the live systemd state (active / inactive / failed / not installed) of the site's sensor units, with a status dot per service.

The set of services is taken from AOS_SERVICES in the site config. The default includes cotbridge, adsbcot, aiscot, dronecot-dji, lincot, and gutcheck. This is a read-only status list. Start, stop, enable, or restart individual services from each gateway's own Cockpit page, or restart them all with Save & restart sensors.

Software updates¶

What it does. Checks for and installs updates from the signed Sensors & Signals package repository, plus Debian security fixes.

Check for updates refreshes package lists and lists what is upgradable (name, current > candidate version), any held-back packages, and when the check ran.
Install all updates applies them. The card shows the AryaOS version and a live log.

Backend: the aryaos-update helper running under aryaos-update.service.

Safe to leave the page

Because the upgrade runs in its own systemd unit, it survives a closed browser. You can navigate away and the install continues. Sensor services can restart briefly while updates apply. A reboot can be required to finish some updates (the summary will say so). Debian security fixes are applied automatically every day. For per-package operations, use Cockpit's Software Updates (PackageKit) page. See Updates.

readsb is held

readsb is apt-mark hold on the image so decoder updates do not silently change your ADS-B pipeline.

Support bundle¶

What it does. Generates a diagnostics tarball for troubleshooting and field reports.

Press Generate support bundle. Collection takes up to a minute. When it finishes, Download the tarball. The card remembers the last bundle's name, size, and timestamp.

The bundle contains system, package and service state, recent journals, network/firewall state, and sensor configs.

What is redacted

Passwords, tokens, and enrollment credentials are redacted, and TLS keys are never included, so a bundle is safe to share with support. See Support bundles.

Backend: the aryaos-support-bundle helper.

Node-RED admin password¶

What it does. Sets the Node-RED editor's admin password.

Enter and confirm a password of at least 8 characters and press Set Node-RED password. Node-RED restarts after the change.

Rotate this before fielding a unit

Node-RED ships with a publicly known default admin password (aryaos415), and its editor can run code on this device. Set a unique password before deploying. See Security posture and Node-RED dashboard.

Backend: the aryaos-set-nodered-password helper (reads the new password on stdin).

VPN (Tailscale)¶

What it does. Joins this box to your Tailscale tailnet for remote access without port forwarding.

The card shows the current state (Connected / Not logged in / Logged in but disconnected / daemon not running) and offers:

Start Tailscale service - appears when the daemon is not running. enables and starts tailscaled.
Connect (get login link) - runs tailscale up and shows a one-time https://login.tailscale.com/... link. Open it on any signed-in device to authorize this node.
Cancel login - abort a pending login.
Disconnect - tailscale down (stays logged in).
Log out of tailnet - tailscale logout. The node needs a new login link to rejoin.

When connected, the card shows the node's tailnet DNS name and IPs.

See VPN (Tailscale).

Nearby AryaOS nodes¶

What it does. Lists other AryaOS units heard on the local Mesh SA network, so you can see and reach neighbors without a central server.

Each AryaOS box beacons a structured <__aryaos> CoT detail through LINCOT. GutCheck combines those beacons with DNS-SD and SSDP identity discovery and caches nearby nodes. The table refreshes every 8 seconds and shows, per node:

Column	Meaning
Node	Hostname (or UID / source IP)
Roles	ADS-B / AIS / UAS, or "base"
Health	Load, memory %, CPU °C, and active/total sensor services
Position	Latitude/longitude, or "no fix"
Seen	Age of the last beacon
Admin	Open link to that node's admin console

This is a read-only discovery view. Use the Open link to jump to a neighbor's Cockpit. See Nearby nodes.

Save & restart¶

At the bottom of the page:

Save & restart sensors - writes the site configuration and restarts the sensor units. Changes to the TAK destination, decoder, UAT serial, and TLS fields then take effect.
Save only - writes the file without restarting anything.

Save & restart sensors button

Which cards need Save

Only the top-of-page fields (TAK destination and the site TLS checkbox) and any edits you made in Raw site config are committed by these buttons. The role, hotspot, radios, updates, support, Node-RED, and VPN cards act immediately via their own buttons.

Raw site config (advanced)¶

At the very bottom, an expandable Raw site config section exposes the full /etc/aryaos/aryaos-config.txt in a text area for direct editing.

Saving the form updates known keys in place and preserves everything else. This includes comments. So an edit here to a key the form does not manage (for example the Bluetooth PAN block, PYTAK_MULTICAST_LOCAL_ADDR, or COT_HOST_ID) is kept. Use this escape hatch for keys not surfaced as fields. The full key list is in Site configuration.

Do not edit device identity keys

AryaOS sets DEVICE_SUFFIX and COT_HOST_ID on first boot. Do not change them by hand. See Site configuration.
